ZX480MTH
Excavator
59 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 177,792 lb |
|---|---|
| Fuel Capacity | 232.5 gal |
| Hydraulic Pump Flow Capacity | 261.1 gal/min |
| Hydraulic System Fluid Capacity | 116.3 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 14.6 gal |
| Cooling System Fluid Capacity | 22.5 gal |
| Swing Drive Fluid Capacity | 5.3 gal |
Engine
| Engine Model | SAA6D140E-3 |
|---|---|
| Displacement | 930 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 454.0 hp |
| Aspiration | Turbocharged with aftercooler |
Dimensions
| Ground Clearance | 33 in |
|---|---|
| Height - Top of Cab | 137 in |
| Length of Track on Ground | 198 in |
| Tail Swing Radius | 170 in |
| Width to Outside of Tracks | 167 in |
| Removal Counterweight Clearance | 62 in |
Undercarriage
| Ground Pressure | 13 psi |
|---|---|
| Track Gauge | 138 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 47 |
| Number of Carrier Rollers per Side | 3 |
| Drawbar Pull | 125,660 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 333 in |
|---|---|
| Max Reach Along Ground | 528 in |
| Max Loading Height | 3,243 in |
| Max Vertical Wall Digging Depth | 206 in |
| Max Cutting Height | 472 in |
| Shipping Length of Unit | 547 in |
| Shipping Height of Unit | 192 in |
Bucket
| Reference Bucket Capacity | 5.30 yd³ |
|---|
Swing Mechanism
| Swing Speed | 7 rpm |
|---|
