Hitachi

ZX480MTH

Excavator

Operating Weight
106,924 lb
Max Digging Depth
226 in
Max Digging Depth
239 in
Net Power
314.0 hp
All excavators
Hitachi ZX480MTH Excavator
1 / 5
Image 1 of 5
Image: truck1.eu

Specifications

59 data points

Operating Specifications

Operating Specifications specifications
Operating Weight106,924 lb
Fuel Capacity171.8 gal
Hydraulic Pump Flow Capacity95.2 gal/min
Hydraulic System Fluid Capacity134.8 gal
Hydraulic System Relief Valve Pressure4,980 psi
Engine Oil Capacity14.6 gal
Cooling System Fluid Capacity16.2 gal
Operating Voltage12 V
Swing Drive Fluid Capacity1.8 gal

Engine

Engine specifications
Engine ModelAA-6WG1TQA
Displacement957 in³
Power Measured @1,800 rpm
Net Power314.0 hp
Aspirationturbocharged
Torque Measured @1,500 rpm
Max Torque940 lb-ft

Dimensions

Dimensions specifications
Ground Clearance32 in
Height - Top of Cab137 in
Length of Track on Ground168 in
Tail Swing Radius138 in
Width to Outside of Tracks120 in
Removal Counterweight Clearance56 in

Undercarriage

Undercarriage specifications
Ground Pressure13 psi
Track Gauge115 in
Number of Track Rollers per Side8
Max Travel Speed2.5 mph
Shoe Size24 in
Number of Shoes per Side49

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth226 in
Max Reach Along Ground402 in
Max Loading Height292 in
Max Vertical Wall Digging Depth157 in
Max Cutting Height424 in
Shipping Length of Unit466 in
Shipping Height of Unit138 in

Bucket

Bucket specifications
Reference Bucket Capacity2.50 yd³
Maximum Bucket Capacity3.51 yd³
Minimum Bucket Capacity1.60 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth239 in
Max Vertical Wall Digging Depth174 in
Max Cutting Height428 in
Max Loading Height296 in
Max Reach Along Ground414 in
Shipping Length of Unit466 in
Shipping Height of Unit138 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth281 in
Max Cutting Height403 in
Max Loading Height283 in
Max Vertical Wall Digging Depth157 in
Max Reach Along Ground437 in
Shipping Length of Unit466 in
Shipping Height of Unit138 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth304 in
Max Cutting Height441 in
Max Reach Along Ground466 in
Max Loading Height305 in
Max Vertical Wall Dig Depth260 in
Shipping Length of Unit466 in
