KomatsuZettelmeyer
ZL5001
Wheel Loader
35 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 81,571 lb |
|---|---|
| Fuel Capacity | 165.9 gal |
| Tire Size | 29.5-29-22PR (L-4) |
| Static Tipping Weight | 59,966 lb |
| Turning Radius | 341 in |
| Rear Axle Oscillation | 26 ° |
| Cooling System Fluid Capacity | 26.5 gal |
Engine
| Engine Model | KT1150-C |
|---|---|
| Displacement | 1,150 in³ |
| Gross Power | 415.0 hp |
| Aspiration | turbocharged |
Hydraulic System
| Raise Time | 8.1 s |
|---|---|
| Lower Time | 5.0 s |
| Dump Time | 3.2 s |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 157 in |
| Wheelbase | 156 in |
| Width Over Tires | 137 in |
| Reach at Max Lift and Dump | 56 in |
| Length with Bucket on Ground | 367 in |
| Hinge Pin - Max Height | 194 in |
Transmission
| Max Speed - Forward | 20.3 mph |
|---|---|
| Max Speed - Reverse | 20.3 mph |
| Transmission Type | TORQFLOW full powershift countershaft type |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 7.49 yd³ |
|---|---|
| Dump Clearance at Max Raise | 148 in |
| Breakout Force | 81,790 lb |
| Bucket Width | 145 in |
