Komatsu
Manitou
ML40
Wheel Loader
20 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 10,318 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| Tire Size | 42x17-20-10PR (L-2) |
| Static Tipping Weight | 6,482 lb |
| Turning Radius | 172 in |
| Cooling System Fluid Capacity | 3.2 gal |
Engine
| Engine Model | 4D94 |
|---|---|
| Displacement | 179 in³ |
| Gross Power | 49.0 hp |
Hydraulic System
| Raise Time | 5.6 s |
|---|---|
| Lower Time | 4.0 s |
| Dump Time | 1.9 s |
Dimensions
| Height - Top of Cab | 113 in |
|---|---|
| Wheelbase | 85 in |
| Width Over Tires | 74 in |
| Reach at Max Lift and Dump | 37 in |
| Length with Bucket on Ground | 187 in |
| Hinge Pin - Max Height | 120 in |
Transmission
| Max Speed - Forward | 15.6 mph |
|---|---|
| Max Speed - Reverse | 6.3 mph |
| Transmission Type | TORQFLOW full powershift countershaft |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 1 |
Bucket
| Bucket Capacity - heaped | 1.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 95 in |
| Breakout Force | 7,610 lb |
| Bucket Width | 77 in |
