Wacker Neuson
WL18
Wheel Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 6,460 lb |
|---|---|
| Fuel Capacity | 11.9 gal |
| Tire Size | 10.5-18 |
| Hydraulic System Fluid Capacity | 11.9 gal |
| Static Tipping Weight | 5,247 lb |
| Operating Voltage | 12 V |
| Turning Radius | 138 in |
| Rear Axle Oscillation | 25 ° |
Engine
| Power Measured @ | 3,000 rpm |
|---|---|
| Gross Power | 34.9 hp |
| Number of Cylinders | 2 |
| Aspiration | natural |
Hydraulic System
| Raise Time | 6.0 s |
|---|---|
| Lower Time | 6.5 s |
| Relief Valve Setting | 2,611 psi |
| Pump Type | gear pump |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 98 in |
| Wheelbase | 72 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 23 in |
| Length with Bucket on Ground | 172 in |
| Hinge Pin - Max Height | 107 in |
Transmission
| Max Speed - Forward | 11.9 mph |
|---|---|
| Transmission Type | hydrostatic reversibe and shiftable |
Bucket
| Bucket Capacity - heaped | 0.60 yd³ |
|---|---|
| Bucket Capacity - struck | 0.50 yd³ |
| Dump Clearance at Max Raise | 86 in |
| Breakout Force | 562,022 lb |
| Bucket Width | 66 in |
