Komatsu
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 20,790 lb |
|---|---|
| Fuel Capacity | 45.5 gal |
| Tire Size | 17.5-25 12PR (L-2) |
| Static Tipping Weight | 14,992 lb |
| Turning Radius | 217 in |
| Rear Axle Oscillation | 30 ° |
| Cooling System Fluid Capacity | 9.3 gal |
Engine
| Engine Model | 6D105 |
|---|---|
| Displacement | 396 in³ |
| Gross Power | 107.0 hp |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 109 in |
| Width Over Tires | 94 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 258 in |
| Hinge Pin - Max Height | 143 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.5 mph |
| Transmission Type | full powershift countershaft soft shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 110 in |
| Breakout Force | 19,380 lb |
| Bucket Width | 97 in |
