Komatsu
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 20,569 lb |
|---|---|
| Fuel Capacity | 45.0 gal |
| Tire Size | 17.5 R25 |
| Static Tipping Weight | 17,483 lb |
| Operating Voltage | 24 V |
| Turning Radius | 215 in |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 35 A |
Engine
| Engine Model | S6D102 E1 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 110.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 38.1 gal/min |
|---|---|
| Raise Time | 5.0 s |
| Lower Time | 2.5 s |
| Dump Time | 1.1 s |
| Relief Valve Setting | 3,046 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 122 in |
| Wheelbase | 107 in |
| Width Over Tires | 91 in |
| Reach at Max Lift and Dump | 43 in |
| Length with Bucket on Ground | 260 in |
| Hinge Pin - Max Height | 141 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Transmission Type | Fully automatic full powershift with 'kick-down' system |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.11 yd³ |
|---|---|
| Breakout Force | 20,952 lb |
| Bucket Width | 100 in |
