Komatsu
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 22,586 lb |
|---|---|
| Fuel Capacity | 45.0 gal |
| Tire Size | 17.5 R 25 |
| Hydraulic System Fluid Capacity | 10.9 gal |
| Static Tipping Weight | 15,168 lb |
| Operating Voltage | 24 V |
| Turning Radius | 220 in |
| Engine Oil Fluid Capacity | 5.2 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 3.7 gal |
| Rear Axle/Diff Fluid Capacity | 3.7 gal |
| Cooling System Fluid Capacity | 5.7 gal |
| Transmission Fluid Capacity | 6.3 gal |
Engine
| Engine Model | S6D102-E1 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 112.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbo |
Hydraulic System
| Pump Flow Capacity | 38.1 gal/min |
|---|---|
| Raise Time | 5.0 s |
| Lower Time | 2.5 s |
| Dump Time | 1.1 s |
| Relief Valve Setting | 3,046 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 200 in |
| Wheelbase | 107 in |
| Width Over Tires | 100 in |
| Reach at Max Lift and Dump | 44 in |
| Length with Bucket on Ground | 278 in |
| Hinge Pin - Max Height | 149 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Transmission Type | Fully automatic full powershift with 'kick-down' system |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.11 yd³ |
|---|---|
| Dump Clearance at Max Raise | 103 in |
| Breakout Force | 19,783 lb |
| Bucket Width | 100 in |
