Komatsu
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 23,105 lb |
|---|---|
| Fuel Capacity | 48.7 gal |
| Tire Size | 17.5-25-12PR |
| Static Tipping Weight | 20,216 lb |
| Turning Radius | 228 in |
Engine
| Engine Model | S6D102E |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 130.1 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 115 in |
| Width Over Tires | 94 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 276 in |
| Hinge Pin - Max Height | 145 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.80 yd³ |
|---|---|
| Bucket Capacity - struck | 2.39 yd³ |
| Breakout Force | 20,940 lb |
| Bucket Width | 107 in |
