Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 29,189 lb |
|---|---|
| Fuel Capacity | 49.7 gal |
| Tire Size | 20.5-25-12PR |
| Static Tipping Weight | 24,493 lb |
Engine
| Engine Model | SA6D102E |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,350 rpm |
| Gross Power | 152.9 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 127 in |
| Wheelbase | 120 in |
| Width Over Tires | 102 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 289 in |
| Hinge Pin - Max Height | 154 in |
Transmission
| Max Speed - Forward | 21.2 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 3.30 yd³ |
|---|---|
| Bucket Capacity - struck | 2.80 yd³ |
| Dump Clearance at Max Raise | 115 in |
| Breakout Force | 28,770 lb |
| Bucket Width | 108 in |
