Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 29,432 lb |
|---|---|
| Fuel Capacity | 58.4 gal |
| Tire Size | 17.5-25-12PR |
| Static Tipping Weight | 25,199 lb |
| Turning Radius | 240 in |
Engine
| Engine Model | S6D108 |
|---|---|
| Displacement | 436 in³ |
| Power Measured @ | 2,380 rpm |
| Gross Power | 162.3 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 120 in |
| Width Over Tires | 101 in |
| Reach at Max Lift and Dump | 44 in |
| Length with Bucket on Ground | 295 in |
| Hinge Pin - Max Height | 151 in |
Transmission
| Max Speed - Forward | 21.2 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 3.60 yd³ |
|---|---|
| Bucket Capacity - struck | 3.10 yd³ |
| Dump Clearance at Max Raise | 110 in |
| Breakout Force | 27,600 lb |
| Bucket Width | 108 in |
