Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
.png)
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Fuel Capacity | 64.7 gal |
|---|---|
| Tire Size | 20.5-25 |
| Hydraulic System Fluid Capacity | 23.7 gal |
| Turning Radius | 214 in |
| Engine Oil Fluid Capacity | 6.1 gal |
| Front Axle/Diff Fluid Capacity | 7.1 gal |
| Rear Axle/Diff Fluid Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 6.1 gal |
| Rated Bucket Capacity | 3.70 – 4.20 yd³ |
Engine
| Engine Model | SAA6D107E-2 |
|---|---|
| Power Measured @ | 2,100 rpm |
| Gross Power | 173.0 hp |
| Net Power | 165.0 hp |
| Number of Cylinders | 6 |
| Aspiration | TURBOCHARGED |
Weights
| Operating Weight | 33,731 – 33,984 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 29.1 gal/min |
|---|---|
| Raise Time | 5.7 s |
| Lower Time | 3.3 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 2,700 psi |
| Pump Type | GEAR TYPE PUMP |
Transmission
| Max Speed - Forward | 23.6 mph |
|---|---|
| Max Speed - Reverse | 23.6 mph |
| Transmission Type | HYDROSTATIC |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Dump Clearance at Max Raise | 113 in |
|---|
