Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Rated Bucket Capacity | 3.00 – 4.20 yd³ |
|---|
Engine
| Net Power | 165.0 hp |
|---|
Weights
| Operating Weight | 34,128 – 34,987 lb |
|---|
Bucket
| Dump Clearance at Max Raise | 113 in |
|---|
General Specifications
| Operating Weight | 34,128 - 34,987 (15,480 - 15,870) — Starting 2019 Model Year |
|---|---|
| Operating Weight lbs (kg) | 34,128 - 34,987 (15,480 - 15,870) — Starting 2025 Model Year |
| Bucket Capacity | 3.0 - 4.2 (2.3 - 3.2) — Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 3.0 - 4.2 (2.3 - 3.2) — Starting 2025 Model Year |
| Engine type | SAA6D107E-3 — Starting 2019 Model Year |
| Engine Power | 165 (123) — Starting 2019 Model Year |
| Max Dump Height | 9.4 (2.8) — Starting 2024 Model Year |
| Max Dump Height ft.( m) | 9.5 (2.8) — Starting 2026 Model Year |
| OperatingWeight lbs. (kg) | 34,128 - 34,987 (15,480 - 15,870) — Starting 2026 Model Year |
| Engine Power Net hp (kW) | 165 (123) — Starting 2025 Model Year |
