Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 35,902 lb |
|---|---|
| Fuel Capacity | 75.9 gal |
| Tire Size | 20.5-25-16PR |
| Static Tipping Weight | 27,514 lb |
| Turning Radius | 253 in |
Engine
| Engine Model | S6D108 |
|---|---|
| Displacement | 436 in³ |
| Gross Power | 187.8 hp |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 131 in |
| Wheelbase | 126 in |
| Width Over Tires | 107 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 315 in |
| Hinge Pin - Max Height | 159 in |
Transmission
| Max Speed - Forward | 19.6 mph |
|---|---|
| Max Speed - Reverse | 20.2 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.20 yd³ |
|---|---|
| Bucket Capacity - struck | 3.60 yd³ |
| Dump Clearance at Max Raise | 115 in |
| Breakout Force | 33,300 lb |
| Bucket Width | 115 in |
