Komatsu
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight 4wd | 18,276 lb |
|---|---|
| Fuel Capacity | 29.1 gal |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Cooling System Fluid Capacity | 4.8 gal |
| Tire Size Front - 2wd / 4wd | 16/70 x 24 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.4 gal |
| Alternator Supplied Amperage | 60 A |
| Max Weight | 19,290 lb |
| Rear Axle Fluid Capacity | 2.7 gal |
| Front Axle Fluid Capacity | 3.2 gal |
Engine
| Engine Model | S4D106-1FC |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 113.0 hp |
| Net Power | 96.6 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 43.6 gal/min |
|---|---|
| Relief Valve Pressure | 2,901 psi |
| Pump Type | gear pumps |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 94 in |
| Transport Width | 89 in |
| Height to Top of Suspended Cab | 115 in |
Transmission
| Max Speed | 22.4 mph |
|---|---|
| Max Speed - Reverse | 22.4 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Hydrostatic |
Tires & Wheels
| Rear Tires Size | 16/70 x 24 |
|---|
Backhoe
| Dig Depth | 178 in |
|---|---|
| Reach From Swivel | 220 in |
| Dig Depth - Extended | 223 in |
| Load Height - Extended | 200 in |
| Bucket Dig Force | 13,065 lb |
| Reach From Swivel - Extended | 258 in |
| Reach at Load Height - Extended | 142 in |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Clearance at Max Dump Height | 110 in |
| Bucket Breakout Force | 14,275 lb |
| Bucket Width | 89 in |
| Reach at Max Dump Height | 36 in |
| Dig Depth | 3 in |
