Komatsu

WF22T-2

Landfill Compactor

Operating Weight
47,399 lb
Max Speed
12.0 mph
Gross Power
230.0 hp
All landfill compactors
Komatsu WF22T-2 Landfill Compactor
1 / 5
Image 1 of 5
Image: komatsustores.com

Specifications

24 data points

Operating Specifications

Operating Specifications specifications
Operating Weight47,399 lb
Fuel Capacity105.7 gal
Hydraulic System Fluid Capacity50.2 gal
Engine Oil Capacity11.7 gal
Cooling System Fluid Capacity15.9 gal
Transmission Fluid Capacity26.5 gal

Engine

Engine specifications
Engine ModelNTC-743-C
Displacement743 in³
Gross Power230.0 hp
Aspirationturbocharged

Dimensions

Dimensions specifications
Ground Clearance22 in
Height - Top of Cab149 in
Wheelbase137 in
Width Over Wheels134 in

Transmission

Transmission specifications
Max Speed12.0 mph
Number of Forward Gears3
Number of Reverse Gears3
Transmission Typeplanetary gear

Blades

Blades specifications
Blade Width163 in
Blade Height75 in

Wheels

Wheels specifications
Front Wheels Drum Diameter55 in
Front Wheels Drum Width41 in
Rear Wheels Drum Diameter55 in
Rear Wheels Drum Width41 in
