Krupp
KMK3045
- Gross Power
- 296.4 hp
- Max Lift Capacity
- 90,000 lb
- Max Speed - Forward
- 42.0 mph
- Transport Width
- 98 in
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 79,500 lb |
|---|---|
| Tire Size | 14.00R25 |
| Carrier Fuel Capacity | 80.0 gal |
| Operating Voltage | 24 V |
| Number of Axels | 3 |
| Alternator Supplied Amperage | 55 A |
Dimensions
| Transport Width | 98 in |
|---|---|
| Transport Height | 143 in |
| Transport Length | 445 in |
| Width w/ Outriggers Extended | 224 in |
| Upper Structure Tail Swing Radius | 128 in |
| Carrier Length | 344 in |
Transmission
| Max Speed - Forward | 42.0 mph |
|---|---|
| Max Speed - Reverse | 10.9 mph |
| Transmission Type | ZF 6-gear powershift 6 WG 200 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 2 |
Boom
| Max Lift Capacity | 90,000 lb |
|---|---|
| Number of Sections | 3 |
| Max Height @ Max Raise Angle - no jib | 1,344 in |
| Min Height @ Max Raise Angle | 528 in |
| Max Elevating Angle | 84 ° |
| Swing Speed | 3 rpm |
| Min Working Radius | 120 in |
| Max Working Radius | 1,260 in |
CARRIER ENGINE
| Gross Power | 296.4 hp |
|---|---|
| Max Torque | 811 lb-ft |
| Torque Measured @ | 1,500 rpm |
| Make | Krupp |
| Power Measured @ | 2,100 rpm |
UPPER STRUCTURE ENGINE
| Make | Krupp |
|---|
