KubotaKubota
B2920
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 1,433 lb |
|---|---|
| Fuel Capacity | 6.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 1,058 lb |
| 3 Point Hitch Type | cat. I |
| Turning Radius | 83 in |
| Cooling System Fluid Capacity | 1.2 gal |
| Engine Oil Capacity | 0.8 gal |
Engine
| Engine Model | D1005 |
|---|---|
| Displacement | 61 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 23.0 hp |
| Number of Cylinders | 3 |
| PTO Power | 18.0 hp |
Hydraulic System
| Pump Flow Capacity | 2.2 gal/min |
|---|
Dimensions
| Wheelbase | 62 in |
|---|---|
| Overall Length | 8 in |
| Tire Size | front 6-12 rear 9.5-16 |
| Width Outside Frame | 46 in |
Transmission
| Max Speed | 11.2 mph |
|---|---|
| Number of Forward Gears | 9 |
| Transmission Type | gear |
| Number of Reverse Gears | 3 |
Production
| Series | B2x20 Series |
|---|---|
| Years Manufactured | 2,008 – 2,015 |
Axles
| Final Drive | spud gear |
|---|
