Kubota
Takeuchi
TB175W
Mini Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 26,896 lb |
|---|---|
| Operating weight Cabin | 27,337 lb |
| Fuel Capacity | 19.9 gal |
| Hydraulic Pump Flow Capacity | 11.9 gal/min |
| Hydraulic System Fluid Capacity | 20.9 gal |
| Cooling System Fluid Capacity | 2.2 gal |
| Travel speed, high range | 3.1 mph |
| Travel speed, low range | 1.8 mph |
| Auxiliary hydraulic flow | 19.9 gal/min |
| Auxiliary fuel tank | 9.8 gal |
Engine
| Engine Model | V2607-DI |
|---|---|
| Displacement | 9,739 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 47.6 hp |
| Net Power | 45.2 hp |
| Number of Cylinders | 4 |
| Engine Make | Kubota |
| Model Name | KX057-4G1 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Overall Length | 219 in |
| Overall Width | 77 in |
| Tail Swing Radius | 50 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Shoe Size | 16 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 152 in |
|---|---|
| Max Vertical Wall Digging Depth | 69 in |
| Max.Dumping Height | 166 in |
| Max Digging Height | 227 in |
| Mximum dig radius | 246 in |
Boom
| Boom swing left | 70 ° |
|---|---|
| Boom swing right | 55 ° |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Blades
| Blade Width | 78 in |
|---|---|
| Blade Lift Height | 17 in |
| Maximum Drop below ground | 17 in |
| Overall Height | 101 in |
