Kubota
Caterpillar
305.5E CR
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 16,160 lb |
|---|---|
| Fuel Capacity | 13.3 gal |
| Hydraulic Pump Flow Capacity | 16.5 gal/min |
| Hydraulic System Fluid Capacity | 14.6 gal |
Engine
| Engine Model | D1703-M-E3 |
|---|---|
| Displacement | 92 in³ |
| Power Measured @ | 2,250 rpm |
| Gross Power | 29.6 hp |
| Net Power | 28.3 hp |
| Engine Make | Kubota |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 97 in |
| Length of Track on Ground | 189 in |
| Tail Swing Radius | 52 in |
| Width to Outside of Tracks | 61 in |
| Traction force | 5,599,741 lb |
Undercarriage
| Max Travel Speed | 3.0 mph |
|---|---|
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 126 in |
|---|---|
| Max Reach Along Ground | 203 in |
| Max Vertical Wall Digging Depth | 110 in |
| Max Loading Height | 139 in |
| Max Cutting Height | 196 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
