Kubota
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 5.1 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 3.5 gal/min |
| Hydraulic System Fluid Capacity | 6.1 gal |
| Travel speed, high range | 2.6 mph |
| Travel speed, low range | 1.4 mph |
| Auxiliary hydraulic flow | 7.4 gal/min |
Engine
| Engine Model | D902-E3 |
|---|---|
| Displacement | 3,344 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 17.0 hp |
| Number of Cylinders | 3 |
| Engine Make | Kubota |
| Model Name | U17-HGS |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Overall Length | 141 in |
| Tail Swing Radius | 25 in |
| Crawler length | 64 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Shoe Size | 9 in |
| Drawbar Pull | 4,865 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 91 in |
|---|---|
| Max Vertical Wall Digging Depth | 76 in |
| Max.Dumping Height | 97 in |
| Max Digging Height | 141 in |
| Mximum dig radius | 154 in |
General Specifications
| Operating Weight lbs (kg) | 3,703 (1,680) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 7.8 (2.3) Starting 2025 Model Year |
| Engine hp (kW) | 15.2 (11) Starting 2025 Model Year |
| Digging Reach ft. (m) | 12.8 (3.9) Starting 2025 Model Year |
Boom
| Boom swing left | 65 ° |
|---|---|
| Boom swing right | 58 ° |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Blades
| Blade Lift Height | 11 in |
|---|---|
| Maximum Drop below ground | 8 in |
| Overall Height | 93 in |
