Kubota
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Fuel Capacity | 10.6 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 20.6 gal/min |
| Hydraulic System Fluid Capacity | 9.5 gal |
| Engine Oil Capacity | 1.4 gal |
| Cooling System Fluid Capacity | 1.5 gal |
Engine
| Engine Model | D1503 - M |
|---|---|
| Displacement | 92 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 28.0 hp |
| Number of Cylinders | 3 |
| Aspiration | liquid-cooled overhead valve diesel engine |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Width to Outside of Tracks | 67 in |
| Digging Depth | 124 in |
| Digging Reach | 124 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Max Travel Speed | 2.9 mph |
| Drawbar Pull | 6,098 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 125 in |
|---|---|
| Max Reach Along Ground | 203 in |
| Max Vertical Wall Digging Depth | 89 in |
| Max Loading Height | 139 in |
| Shipping Length of Unit | 186 in |
| Max Cutting Height | 196 in |
| Shipping Height of Unit | 97 in |
