Leeboy
Dynapac
F5CS
Asphalt Paver
17 specifications
1 / 5
Image 1 of 5
Specifications
10 data points
Operating Specifications
| Operating Weight w/o Screed | 15,900 lb |
|---|---|
| Fuel Capacity | 20.1 gal |
| Hydraulic System Fluid Capacity | 39.9 gal |
Engine
| Gross Power | 74.0 hp |
|---|
Dimensions
| Transport Width | 103 in |
|---|---|
| Transport Height | 78 in |
| Length w/o Screed | 150 in |
Hopper/Paver
| Paving Width - max | 180 in |
|---|---|
| Paving Speed - max | 1.8 mph |
| Travel Speed - max | 3.1 mph |
