Caterpillar
988K XE
Wheel Loader
57 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Fuel Capacity | 629.7 gal |
|---|---|
| Tire Size | 50/65-51 62PR |
| Hydraulic System Fluid Capacity | 260.0 gal |
| Static Tipping Weight | 179,203 lb |
| Engine Oil Fluid Capacity | 24.9 gal |
| Rear Axle Oscillation | 22 ° |
| Cooling System Fluid Capacity | 88.0 gal |
Engine
| Engine Model | 16V Series 2000 |
|---|---|
| Displacement | 1,944 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 1,205.0 hp |
| Aspiration | Turbocharged |
Hydraulic System
| Raise Time | 12.0 s |
|---|---|
| Lower Time | 5.0 s |
| Dump Time | 3.0 s |
Dimensions
| Ground Clearance | 29 in |
|---|---|
| Height - Top of Cab | 229 in |
| Wheelbase | 243 in |
| Width Over Tires | 202 in |
Transmission
| Max Speed - Forward | 12.0 mph |
|---|---|
| Max Speed - Reverse | 12.0 mph |
Bucket
| Bucket Width | 217 in |
|---|
