Liebherr
Tata Hitachi
EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 25,574 lb |
|---|---|
| Fuel Capacity | 56.8 gal |
| Hydraulic Pump Flow Capacity | 58.2 gal/min |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
| Hydraulic Pump Type | Variable Displacement Swashplate Pump |
| Tire Size | 9.00-20 |
Engine
| Engine Model | BF4M2012 |
|---|---|
| Displacement | 244 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 91.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Direct Injection Turbo-charged |
Transmission
| Max Travel Speed | 12.5 mph |
|---|---|
| Transmission Type | Oversized two speed power shift transmission and integrated protection with additional creeper speed |
Bucket
| Reference Bucket Capacity | 0.41 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.41 yd³ |
| Minimum Bucket Capacity | 0.20 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 162 in |
|---|---|
| Max Cutting Height | 263 in |
| Max Reach Along Ground | 331 in |
| Max Loading Height | 267 in |
| Shipping Length of Unit | 343 in |
