Liebherr
Hitachi
EX135USR
Excavator
23 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Operating Weight | 30,424 lb |
|---|---|
| Fuel Capacity | 56.8 gal |
| Hydraulic Pump Flow Capacity | 60.8 gal/min |
| Hydraulic System Fluid Capacity | 84.6 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
| Hydraulic Pump Type | Variable Displacement Swashplate Pump |
Engine
| Engine Model | BF4M1013E |
|---|---|
| Displacement | 293 in³ |
| Power Measured @ | 18,000 rpm |
| Net Power | 102.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Direct injection turbo-charged |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 101 in |
| Overall Width | 8 in |
| Tail Swing Radius | 76 in |
| Upper Structure Clearance | 48 in |
| Overall Width - Outriggers Down | 149 in |
Transmission
| Max Travel Speed | 12.5 mph |
|---|---|
| Transmission Type | Oversized two speed power shift trandmission and integrated protection with additional creeper speed |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.99 yd³ |
| Minimum Bucket Capacity | 0.20 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 25 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 198 in |
|---|---|
| Max Cutting Height | 377 in |
| Max Reach Along Ground | 325 in |
| Max Loading Height | 264 in |
| Shipping Length of Unit | 319 in |
| Shipping Height of Unit | 124 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 205 in |
|---|---|
| Max Cutting Height | 383 in |
| Max Reach Along Ground | 333 in |
| Max Loading Height | 270 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 304 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 183 in |
|---|---|
| Max Cutting Height | 324 in |
| Max Reach Along Ground | 307 in |
| Max Loading Height | 214 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 341 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 192 in |
|---|---|
| Max Cutting Height | 328 in |
| Max Reach Along Ground | 316 in |
| Max Loading Height | 217 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 328 in |
