Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 26,676 lb |
|---|---|
| Tire Size | 20.5R25 |
| Static Tipping Weight | 19,015 lb |
| Turning Radius | 115 in |
Engine
| Engine Model | D504Ti |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 134.2 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 115 in |
| Width Over Tires | 95 in |
| Reach at Max Lift and Dump | 39 in |
| Length with Bucket on Ground | 285 in |
Transmission
| Max Speed - Forward | 21.2 mph |
|---|---|
| Max Speed - Reverse | 21.2 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 3.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 114 in |
| Bucket Width | 100 in |
