LiebherrLiebherr
LR614
Crawler Loader
36 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 35,100 lb |
|---|---|
| Bucket Capacity - struck | 2.30 yd³ |
| Fuel Capacity | 68.7 gal |
| Static Tipping Load | 23,369 lb |
| Breakout Force Bucket | 30,574 lb |
| Cooling System Fluid Capacity | 11.1 gal |
| Hydraulic System Fluid Capacity | 34.4 gal |
| Final Drive Fluid Capacity - each | 3.5 gal |
| Engine Oil Capacity | 4.8 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | D 924 T-E |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 132.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbo-charged |
Hydraulic System
| Pump Flow Capacity | 41.3 gal/min |
|---|---|
| Relief Valve Pressure | 3,770 psi |
| Pump Type | swash plate piston pump |
Dimensions
| Ground Clearance | 187 in |
|---|---|
| Height - Top of Cab | 124 in |
| Width to Outside of Tracks | 97 in |
| Length with Bucket on Ground | 241 in |
| Reach at Dump Height | 41 in |
| Clearance at Full Height and Dump | 115 in |
| Length to Front of Track | 172 in |
Undercarriage
| Track Gauge | 66 in |
|---|---|
| Track Shoe Width | 20 in |
| Ground Pressure | 9 psi |
| Number of Track Rollers per Side | 6 |
