D150
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 33,510 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Final Drives Fluid Capacity | 2.0 gal |
| Engine Oil Capacity | 5.1 gal |
| Hydraulic Fluid Capacity | 26.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 A |
Engine
| Engine Model | EPA/CARB Tier 4f |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 124.8 hp |
| Aspiration | Turbochanged |
| Cooling system | Hydrostatic fan drive |
Hydraulic System
| Pump Flow Capacity | 25.7 gal/min |
|---|---|
| Pump Type | Gear pump |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 103 in |
| Width Over Tracks | 93 in |
| Track Gauge | 71 in |
Transmission
| Max Speed - Reverse | 2.5 mph |
|---|---|
| Transmission Type | Infinitely variable hydrostatic travel drive |
Undercarriage
| Number of Track Rollers per Side | 7 |
|---|---|
| Number of Carrier Rollers per Side | 1 |
Standard Blade
| Width | 125 in |
|---|---|
| Height | 43 in |
| Capacity | 4.09 yd³ |
