Liebherr
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 54,234 lb |
|---|---|
| Fuel Capacity | 113.6 gal |
| Cooling System Fluid Capacity | 10.9 gal |
| Final Drives Fluid Capacity | 7.1 gal |
| Engine Oil Capacity | 7.7 gal |
| Hydraulic Fluid Capacity | 29.4 gal |
Engine
| Engine Model | D 934 A7 - Tier 4 Final |
|---|---|
| Displacement | 427 in³ |
| Gross Power | 201.2 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 130 in |
| Length of Track on Ground | 128 in |
| Width Over Tracks | 122 in |
| Length w/ Blade | 230 in |
| Length w/o Blade | 175 in |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 6.8 mph |
| Transmission Type | Variable hydrostatic travel drive |
Undercarriage
| Number of Track Rollers per Side | 7 |
|---|---|
| Number of Carrier Rollers per Side | 2 |
| Standard Shoe Size | 32 in |
Standard Blade
| Width | 159 in |
|---|---|
| Height | 4 in |
| Capacity | 6.10 yd³ |
| Blade Angle (both directions) | 20 ° |
