Liebherr
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 52,500 lb |
|---|---|
| Fuel Capacity | 118.9 gal |
| Cooling System Fluid Capacity | 16.4 gal |
| Final Drives Fluid Capacity | 6.1 gal |
| Engine Oil Capacity | 5.9 gal |
| Hydraulic Fluid Capacity | 50.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | D 926 TI-E |
|---|---|
| Displacement | 610 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 234.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbo-charged |
Hydraulic System
| Pump Flow Capacity | 77.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,320 psi |
| Pump Type | Load sensing Proportional pump flow control |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 131 in |
| Length of Track on Ground | 130 in |
| Width Over Tracks | 106 in |
| Length w/ Blade | 228 in |
| Length w/o Blade | 170 in |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 4.9 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 2 |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Track Gauge | 78 in |
| Number of Track Rollers per Side | 8 |
| Standard Shoe Size | 20 in |
| Ground Contact Area | 5,115 in³ |
Standard Blade
| Width | 157 in |
|---|---|
| Height | 57 in |
| Capacity | 8.40 yd³ |
