Liebherr
Komatsu
D87E-3
Crawler Dozer
41 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 54,245 lb |
|---|
Engine
| Engine Model | D936-LA6 |
|---|---|
| Displacement | 641 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 246.8 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 131 in |
| Length of Track on Ground | 119 in |
| Length w/ Blade | 216 in |
| Length w/o Blade | 170 in |
Transmission
| Max Speed - Forward | 6.9 mph |
|---|---|
| Max Speed - Reverse | 6.9 mph |
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Track Gauge | 78 in |
| Standard Shoe Size | 24 in |
Standard Blade
| Width | 157 in |
|---|---|
| Height | 57 in |
| Capacity | 8.40 yd³ |
