Liebherr
Komatsu
PC800-6
Excavator
28 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 223,110 lb |
|---|
Engine
| Engine Model | D9508 A7 SCR |
|---|---|
| Displacement | 986 in³ |
| Power Measured @ | 1,800 rpm |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 2,210 lb-ft |
| Stroke | 6 in |
| Bore | 5 in |
| Emission Tier Level | Tier 4 Final |
| Air cleaner | Dry-type |
| Cooling system | water-cooled |
| Horsepower, Net-ISO 9249 | 563.0 hp |
| Horsepower, Net-SAE J1349 | 571.0 hp |
Hydraulic System
| system pressure | 5,076 psi |
|---|
Dimensions
| Ground Clearance | 33 in |
|---|---|
| Height - Top of Cab | 156 in |
| Wheelbase | 191 in |
| Undercarriage Width | 178 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Max Travel Speed | 2.3 mph |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 145,002 lb |
Fluid Capacities
| Fuel Tank | 396.0 gal |
|---|---|
| Hydraulic system | 300.0 gal |
| Urea tank | 48.0 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 278 in |
|---|---|
| Max.Dumping Height | 340 in |
| Maximum Reach at Ground Level | 485 in |
| Max. teeth height | 502 in |
| Breakout force - ISO | 113,760 lb |
| Digging force - ISO | 95,680 lb |
Bucket
| Maximum Bucket Capacity | 8.89 yd³ |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 424 in |
|---|---|
| Max.Dumping Height | 346 in |
| Max. teeth height | 506 in |
| Maximum Reach at Ground Level | 42 in |
| Breakout force-ISO | 113,760 lb |
| Digging force - ISO | 88,630 lb |
Electrical System
| Batteries | 2 x 180 Ah / 12 V volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
| Engine idling | Sensor controlled |
