Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Fuel Capacity | 45.0 gal |
|---|---|
| Tire Size | 20.5 R25 |
| Engine Oil Capacity | 3.7 gal |
| Cooling System Fluid Capacity | 8.2 gal |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Transmission Fluid Capacity | 5.9 gal |
Engine
| Engine Model | 6BT5.9 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 137.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 452 lb-ft |
Weights
| Total Empty | 22,323 lb |
|---|---|
| Front Axle - empty | 14,158 lb |
| Total Loaded | 54,323 lb |
| Rear Axle - empty | 8,165 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 158 in |
| Overall Length | 282 in |
| Overall Width | 100 in |
| Overall Height | 128 in |
| Dump Height | 186 in |
| Dump Ground Clearance | 39 in |
Transmission
| Max Speed | 29.7 mph |
|---|---|
| Transmission Type | Power Shift |
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 4 |
Dump
| Rated Payload | 32,000 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 16.0 s |
| Lower Time | 20.0 s |
| Capacity - Heaped | 11.80 yd³ |
| Capacity - Struck | 9.50 yd³ |
