Link Belt
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 85.9 gal |
|---|---|
| Tire Size | 23.5 R25 |
| Engine Oil Capacity | 9.0 gal |
| Cooling System Fluid Capacity | 11.4 gal |
| Hydraulic System Fluid Capacity | 52.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Transmission Fluid Capacity | 5.1 gal |
Engine
| Engine Model | M11-C270 |
|---|---|
| Displacement | 661 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 270.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and Aftercooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 910 lb-ft |
Weights
| Total Empty | 39,682 lb |
|---|---|
| Front Axle - empty | 19,841 lb |
| Total Loaded | 99,208 lb |
| Rear Axle - empty | 19,841 lb |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 216 in |
| Overall Length | 385 in |
| Overall Width | 113 in |
| Overall Height | 132 in |
Transmission
| Max Speed | 30.0 mph |
|---|---|
| Transmission Type | Power Shift |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Dump
| Rated Payload | 60,000 lb |
|---|---|
| Capacity - Heaped | 21.59 yd³ |
| Capacity - Struck | 17.00 yd³ |
