Link Belt
Tadano
TR-600XXL-4
Rough Terrain Crane
Specifications pending
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Fuel Capacity | 100.0 gal |
|---|
Engine
| Displacement | 318 in³ |
|---|---|
| Power Measured @ | 2,700 rpm |
| Gross Power | 205.0 hp |
| Number of Cylinders | 6 |
| Max Torque | 445 lb-ft |
| Stroke | 5 in |
| Bore | 4 in |
| Crankcase capacity | 4.6 gal |
Hydraulic System
| Maximum operating pressure | 2,900 psi |
|---|
Dimensions
| Wheelbase | 151 in |
|---|---|
| Transport Width | 103 in |
| Transport Height | 151 in |
| Transport Length | 553 in |
| Width w/ Outriggers Extended | 289 in |
| Upper Structure Tail Swing Radius | 300 in |
| Carrier/Base Length | 329 in |
Transmission
| Number of Forward Gears | 6 |
|---|---|
| Number of Reverse Gears | 2 |
Boom
| Max Height @ Max Raise Angle - no jib | 1,021 in |
|---|---|
| Min Height @ Max Raise Angle | 421 in |
| Max Elevating Angle | 78 ° |
| Number of Sections | 3 |
| Swing Speed | 3 rpm |
