Link Belt
RTC-8030
Rough Terrain Crane
32 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 54,120 lb |
|---|---|
| Fuel Capacity | 60.0 gal |
| Tire Size | 16.00x25 28PR |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 137.0 gal |
| Alternator Supplied Amperage | 90 A |
| Cooling System Fluid Capacity | 10.6 gal |
Engine
| Engine Model | V504C |
|---|---|
| Displacement | 504 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 156.0 hp |
| Number of Cylinders | 8 |
| Aspiration | natural |
| Torque Measured @ | 1,900 rpm |
| Max Torque | 339 lb-ft |
| Engine Make | Cummins Diesel |
| Bore | 5 in |
| Stroke | 4 in |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 12 in |
| Transport Width | 97 in |
| Transport Height | 141 in |
| Transport Length | 480 in |
| Width w/ Outriggers Extended | 240 in |
| Upper Structure Tail Swing Radius | 138 in |
| Carrier/Base Length | 295 in |
Transmission
| Max Speed - Forward | 23.2 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | remote mounted full powershift |
Boom
| Max Lift Capacity | 50,000 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 960 in |
| Min Height @ Max Raise Angle | 384 in |
| Max Elevating Angle | 75 ° |
| Number of Sections | 3 |
| Swing Speed | 3 rpm |
| Min Operating Radius | 144 in |
| Max Operating Radius | 1,200 in |
