Liugong

840II

Wheel Loader

Bucket Capacity - heaped
3.10 yd³
Net Power
173.0 hp
All wheel loaders
Liugong 840II Wheel Loader
1 / 5
Image 1 of 5
Image: evangelchina.en.made-in-china.com

Specifications

34 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity55.5 gal
Hydraulic System Fluid Capacity60.8 gal
Static Tipping Weight17,637 lb
Engine Oil Fluid Capacity5.9 gal
Front Axle/Diff Fluid Capacity9.3 gal
Rear Axle/Diff Fluid Capacity9.0 gal
Transmission Fluid Capacity11.9 gal

Engine

Engine specifications
Engine ModelQSB5.9C173
Displacement360 in³
Power Measured @2,200 rpm
Net Power173.0 hp
Number of Cylinders6
Aspirationturbocharged
Torque Measured @1,500 rpm

Hydraulic System

Hydraulic System specifications
Raise Time6.6 s
Lower Time3.4 s
Dump Time1.1 s
Relief Valve Setting2,611 psi

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab132 in
Wheelbase119 in
Width Over Tires98 in
Reach at Max Lift and Dump41 in
Length with Bucket on Ground296 in
Hinge Pin - Max Height150 in

Transmission

Transmission specifications
Max Speed - Forward23.5 mph
Max Speed - Reverse16.0 mph
Transmission Typecounter shaft-type power shift
Number of Forward Gears4
Number of Reverse Gears3

Bucket

Bucket specifications
Bucket Capacity - heaped3.10 yd³
Dump Clearance at Max Raise115 in
Breakout Force26,977 lb
Bucket Width109 in
