Liugong
John Deere
624K Z-Bar
Wheel Loader
48 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 24,692 lb |
|---|---|
| Tire Size | 17.5-25 |
| Static Tipping Weight | 14,330 lb |
| Turning Radius | 222 in |
Engine
| Engine Model | 6BT5.9 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 111.4 hp |
| Number of Cylinders | 6 |
Hydraulic System
| Pump Type | Gear |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 110 in |
| Width Over Tires | 91 in |
| Reach at Max Lift and Dump | 43 in |
| Length with Bucket on Ground | 267 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 9.4 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 115 in |
| Breakout Force | 21,020 lb |
| Bucket Width | 97 in |
