Liugong
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 30,203 lb |
|---|---|
| Tire Size | 20.5-25 |
| Static Tipping Weight | 17,637 lb |
| Turning Radius | 247 in |
Engine
| Engine Model | B5.9-C |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 147.6 hp |
| Number of Cylinders | 6 |
Hydraulic System
| Pump Type | Gear |
|---|
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 132 in |
| Wheelbase | 119 in |
| Width Over Tires | 98 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 287 in |
Transmission
| Max Speed - Forward | 23.0 mph |
|---|---|
| Max Speed - Reverse | 14.3 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 115 in |
| Breakout Force | 28,101 lb |
| Bucket Width | 109 in |
