Liugong
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 30,203 lb |
|---|---|
| Tire Size | 20.5x25 |
| Static Tipping Weight | 17,637 lb |
| Turning Radius | 247 in |
Engine
| Engine Model | QSB5.9-C175 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 155.6 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 119 in |
| Width Over Tires | 97 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 296 in |
Transmission
| Max Speed - Forward | 23.5 mph |
|---|---|
| Max Speed - Reverse | 16.0 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 115 in |
| Bucket Width | 109 in |
