Liugong
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 31,967 lb |
|---|---|
| Tire Size | 20.5-25 |
Engine
| Engine Model | D6114ZG9B |
|---|---|
| Power Measured @ | 2,200 rpm |
| Net Power | 167.7 hp |
Hydraulic System
| Pump Type | Gear |
|---|
Dimensions
| Height - Top of Cab | 132 in |
|---|---|
| Width Over Tires | 107 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 277 in |
Transmission
| Max Speed - Forward | 21.8 mph |
|---|---|
| Max Speed - Reverse | 8.1 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 1 |
Bucket
| Bucket Capacity - heaped | 2.90 yd³ |
|---|---|
| Dump Clearance at Max Raise | 111 in |
| Breakout Force | 24,729 lb |
