Manitou
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 8,389 lb |
|---|---|
| Max Speed | 13.1 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | front 7.00-12-12PR rear 6.00-9-10PR |
Engine
| Engine Model | 4JG2 |
|---|---|
| Displacement | 187 in³ |
| Power | 60.3 hp |
| Fuel Type | diesel |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 64 in |
| Overall Width | 46 in |
| Turning Radius | 83 in |
| Overall Height - mast lowered | 86 in |
| Length to Fork Face | 97 in |
| Height to Top of Overhead Guard | 84 in |
| Max Fork Height | 133 in |
Mast
| Load Capacity | 4,000 lb |
|---|---|
| Load Center | 20 in |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Max Fork Spread | 45 in |
