Manitou
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 13,625 lb |
|---|---|
| Max Speed | 13.5 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | front 400/70-20 150B T37 STAB TL Backward-10.5/80-18 10PR TG42 TL |
Engine
| Engine Model | Euro 2 1104C 44 |
|---|---|
| Displacement | 269 in³ |
| Torque Measured @ | 1,400 rpm |
| Power | 75.0 hp |
| Torque | 235 lb-ft |
| Cooling system | Water |
| Injection | Direct |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 79 in |
| Overall Width | 76 in |
| Turning Radius | 169 in |
| Overall Height - mast lowered | 108 in |
| Length to Fork Face | 138 in |
| Height to Top of Overhead Guard | 101 in |
| Max Fork Height | 146 in |
Mast
| Load Capacity | 6,614 lb |
|---|---|
| Load Center | 20 in |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Max Fork Spread | 58 in |
| Number of Mast Sections | 1 |
