Massey Ferguson
4880
- Operating Weight
- 34,000 lb
- Displacement
- 903 in³
- Power Measured @
- 2,600 rpm
- Gross Power
- 320.0 hp
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 34,000 lb |
|---|---|
| Fuel Capacity | 190.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 13,000 lb |
| 3 Point Hitch Type | IV |
| Turning Radius | 205 in |
| Alternator Supplied Amperage | 60 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 15.1 gal |
| Hydraulic System Fluid Capacity | 16.0 gal |
| Engine Oil Capacity | 9.4 gal |
| Front Tire Size | 23.1-34 |
| Rear Tire Size | 23.1-34 |
Engine
| Engine Model | V-903 |
|---|---|
| Displacement | 903 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 320.0 hp |
| Number of Cylinders | 8 |
| Aspiration | Liquid cooled |
| Engine Make | Cummins |
| PTO Power | 270.0 hp |
| Stroke | 5 in |
| Bore | 6 in |
Hydraulic System
| Pump Flow Capacity | 60.0 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Hydraulic System Type | Open center |
Dimensions
| Height - Top of Cab | 131 in |
|---|---|
| Wheelbase | 137 in |
| Overall Length | 252 in |
| Width Outside Frame | 108 in |
| Front Axle Clearance | 4 in |
| Shipping weight | 27,000 lb |
| Rear axle clearance | 5 in |
Transmission
| Max Speed - Reverse | 5.9 mph |
|---|---|
| Max Speed - Forward | 19.3 mph |
| Number of Forward Gears | 18 |
| Transmission Type | Partial power shift |
| Number of Reverse Gears | 6 |
Production
| Series | 4000 4WD Series |
|---|---|
| Years Manufactured | 1,978 – 1,983 |
