Massey Ferguson
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Fuel Capacity | 229.9 gal |
|---|---|
| Transmission Type | 2-speed hydrostatic / 4-speed |
| Hydraulic System Fluid Capacity | 22.6 gal |
Engine
| Engine Model | AGCO POWER 98 ATI |
|---|---|
| Displacement | 598 in³ |
| Power Measured @ | 2,100 rpm |
| Number of Cylinders | 7 |
| Power | 460.0 hp |
Cleaning System
| Total Cleaning Area | 9,455 in³ |
|---|---|
| Chaffer area | 4,588 in³ |
Feeding
| Chain size | 4-strand HD #557 |
|---|---|
| Feeder Reverser Control | Electro-hydraulic |
| Housing width | 56 in |
| Stone or Rock Protection | Standard stone trap |
Grain Handling
| Grain Tank Capacity | 3,258.2 gal |
|---|---|
| Unloading Speed | 4.1 bu/sec |
| Unloading Discharge Height | 172 in |
| Unloading Auger Length | 292 in |
| Unloading auger diameter | 15 in |
Separating
| Separating Area | 3,410 in³ |
|---|
Threshing
| Rotor Diameter | 32 in |
|---|---|
| Rotor Length | 140 in |
| Rotor Speed - High | 1,235 rpm |
| Rotor Speed - Low | 264 rpm |
| Concave Area | 2,108 in³ |
| Rotor Type | Segmented element |
