Massey Ferguson
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Fuel Capacity | 229.9 gal |
|---|---|
| Hydraulic System Fluid Capacity | 22.5 gal |
Engine
| Engine Model | AGCO Power™ 98 ATI |
|---|---|
| Displacement | 598 in³ |
| Power Measured @ | 2,100 rpm |
| Number of Cylinders | 7 |
| Power | 460.0 hp |
Cleaning System
| Total Cleaning Area | 992 in³ |
|---|---|
| Total Sieve Area-Fixed | 3,875 in³ |
| Cleaning Fan Description | Transverse 330.0 mm |
| Chaffer area | 4,588 in³ |
Feeding
| Chain size | 4-strand HD #557 |
|---|---|
| Feeder Reverser Control | Electro-hydraulic |
| Housing width | 56 in |
Grain Handling
| Unloading Discharge Height | 172 in |
|---|---|
| Unloading Auger Length | 3,511 in |
| Unloading auger diameter | 15 in |
Separating
| Separating Area | 3,410 in³ |
|---|---|
| Separator Type | Rotary |
| Discharge Grate Area | 2,108 in³ |
Threshing
| Rotor Diameter | 32 in |
|---|---|
| Rotor Length | 140 in |
