Massey Ferguson
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Fuel Capacity | 87.2 gal |
|---|---|
| Transmission Type | mechanical syncromesh |
| Number of Gears | — |
Engine
| Engine Model | 1000-6T |
|---|---|
| Displacement | 363 in³ |
| Power Measured @ | 2,400 rpm |
| Aspiration | turbocharged |
| Power | 168.0 hp |
Dimensions
| Overall Length | 335 in |
|---|---|
| Width Over Tires | 131 in |
| Height to Top of Isomount Cab | 137 in |
Cleaning System
| Total Cleaning Area | 5,580 in³ |
|---|---|
| Cleaning Fan Speed - High | 2,075 rpm |
| Cleaning Fan Speed - Low | 974 rpm |
Feeding
| Conveyor Speed | 60 rpm |
|---|
Grain Handling
| Grain Tank Capacity | 1,321.0 gal |
|---|---|
| Unloading Speed | 1.3 bu/sec |
Separating
| Separating Area | 9,145 in³ |
|---|---|
| Separator Type | 5 straw walkers closed bottom |
Threshing
| Rotor Diameter | 22 in |
|---|---|
| Rotor Length | 50 in |
| Rotor Speed - High | 1,000 rpm |
| Rotor Speed - Low | 365 rpm |
| Concave Area | 1,039 in³ |
