Dynapac
F5CS
Asphalt Paver
17 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Operating Weight w/ Screed | 12,500 lb |
|---|---|
| Fuel Capacity | 13.0 gal |
| Hydraulic System Fluid Capacity | 15.5 gal |
| Operating Voltage | 12 V |
Engine
| Net Power | 60.0 hp |
|---|---|
| Number of Cylinders | 4 |
Dimensions
| Transport Width | 102 in |
|---|---|
| Transport Height | 65 in |
| Length w/ Screed | 125 in |
| Width w/ Hopper Open | 120 in |
Hopper/Paver
| Paving Width - max | 156 in |
|---|---|
| Paving Speed - max | 1.6 mph |
| Travel Speed - max | 3.3 mph |
| Auger Diameter | 9 in |
