New Holland
RG80
Motor Grader
39 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Std Operation Weight - Total | 18,590 lb |
|---|---|
| Tire Size | 15-19.5 |
| Fuel Capacity | 40.0 gal |
| Std Operation Weight - Front Axle | 5,600 lb |
| Std Operation Weight - Rear Axle | 12,990 lb |
| Hydraulic System Fluid Capacity | 20.0 gal |
| Operating Voltage | 12 V |
Engine
| Displacement | 247 in³ |
|---|---|
| Aspiration | turbocharged and aftercooled |
| Max Power | 133.0 hp |
| Net Torque Gears 1-2 | 363 lb-ft |
Dimensions
| Wheelbase | 198 in |
|---|---|
| Overall Length | 276 in |
| Width Over Tires | 90 in |
| Height to Top of Isomount Cab | 109 in |
| Blade Base | 81 in |
| Tandem Axle Wheelbase | 46 in |
Transmission
| Max Speed - Forward | 17.0 mph |
|---|---|
| Max Speed - Reverse | 17.0 mph |
| Number of Gears - Forward | 2 |
| Number of Gears - Reverse | 2 |
| Transmission Type | hydrostatic |
Moldboard
| Moldboard Height | 19 in |
|---|---|
| Moldboard Width | 120 in |
Circle
| Max Lift Above Ground | 14 in |
|---|---|
| Max Reach Outside Tires - Left | 36 in |
| Max Reach Outside Tires - Right | 36 in |
| Blade Tip Angle - Front | 45 ° |
| Blade Tip Angle - Rear | 45 ° |
Front Axle
| Wheel Lean | 20 ° |
|---|---|
| Oscillation - Total | 30 ° |
Steering System
| Turning Radius | 216 in |
|---|---|
| Articulation Angle | 32 ° |
